NUD3124
Automotive Inductive Load
Driver
This MicroIntegrationt part provides a single component solution
to switch inductive loads such as relays, solenoids, and small DC
motors without the need of a free鈭抴heeling diode. It accepts logic
level inputs, thus allowing it to be driven by a large variety of devices
including logic gates, inverters, and microcontrollers.
Features
http://onsemi.com
鈥?/div>
Provides Robust Interface between D.C. Relay Coils and Sensitive
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Logic
Capable of Driving Relay Coils Rated up to 150 mA at 12 Volts
Replaces 3 or 4 Discrete Components for Lower Cost
Internal Zener Eliminates Need for Free鈭扺heeling Diode
Meets Load Dump and other Automotive Specs
3
1
2
SOT鈭?3
CASE 318
STYLE 21
MARKING DIAGRAMS
JW6 D
Typical Applications
JW6 = Specific Device Code
D
= Date Code
鈥?/div>
Automotive and Industrial Environment
鈥?/div>
Drives Window, Latch, Door, and Antenna Relays
6
JW6 D
1
SC鈭?4
CASE 318F
STYLE 7
JW6 = Specific Device Code
D
= Date Code
Benefits
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Reduced PCB Space
Standardized Driver for Wide Range of Relays
Simplifies Circuit Design and PCB Layout
Compliance with Automotive Specifications
INTERNAL CIRCUIT DIAGRAMS
Drain (3)
Drain (6)
Drain (3)
Gate (1)
10 k
100 K
Gate (2)
10 k
100 K
10 k
100 K
Gate (5)
Source (2)
CASE 318
Source (1)
Source (4)
CASE 318F
ORDERING INFORMATION
Device
NUD3124LT1
NUD3124DMT1
Package
SOT鈭?3
SC鈭?4
Shipping
3000/Tape & Reel
3000/Tape & Reel
漏
Semiconductor Components Industries, LLC, 2003
1
August, 2003 鈭?Rev. 5
Publication Order Number:
NUD3124/D
