NTH4302
Product Preview
HD3e Quad N鈭扖hannel
The NTH4302 is the first integrated Quad FET in a single package.
It is the integration of 4 planar TMOS devices. It uses the latest HD3e
TMOS technology from ON Semiconductor, with very high cell
density and improved switching capability
The NTH4302 is a 16-pin leadless device packaged in the new
PInPAKt from ON Semiconductor. The PInPAK is a new flexible
power package that uses the MAP process. The NTH4302 uses the
same MOSFET as the NTD60N02R. However, with the PInPAK
package, various other pairs of MOSFETs can be used to create
additional custom applications.
Features
http://onsemi.com
鈥?/div>
Ultra Low R
DS
(on) Provides Higher Efficiency
鈥?/div>
Very Fast Switching due to Planar Technology and Leadless Package
鈥?/div>
200% Footprint Reduction Compared to Similar DPAK Solution for
the Same Power
鈥?/div>
Up to 80 Amp per FET
鈥?/div>
Very Low V
f
(0.8 mV) Ideal for Synchronous Rectification
鈥?/div>
Specifically Designed for DC-DC Buck Converter in VRM9.1
Application (80 Amp Per Phase, 500 khz)
Application
QUAD TMOS POWER MOSFET
40 AMPERES
24 VOLTS
R
DS(on)
= 7.5 mW
C
iss
= 2050 pF
R
qJC
= 1.3
5C/W
MARKING
DIAGRAM
TBD
CASE TBD
PInPAK
xx
A
WL, L
YY, Y
WW, W
= Specific Device Code
= Assembly Location
= Wafer Lot
= Year
= Work Week
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
DC-DC Converter
Motherboard/Server Buck Converter
Telecom/Industrial Power Supply
Automotive Motor Drive
H-Bridge
PINOUT DIAGRAM
Application Note AND8086/D, 鈥淏oard Mounting Notes for Quad Flat-Pack
No-Lead Package (QFN)鈥? is available on our web site www.onsemi.com.
TBD
ORDERING INFORMATION
Device
NTH4301
Package
ONiPAK
Shipping
TBD
This document contains information on a product under development. ON Semiconductor
reserves the right to change or discontinue this product without notice.
漏
Semiconductor Components Industries, LLC, 2003
1
January, 2003 - Rev. 0
Publication Order Number:
NTH4301/D
