NTE968
Integrated Circuit
3鈥揟erminal Positive Voltage Regulator, 15V
The NTE968 fixed鈥搗oltage regulator is a monolithic integrated circuit in a TO220 type package de-
signed for use in a wide variety of applications including local, on鈥揷ard regulation. This regulator em-
ploys internal current limiting, thermal shutdown, and safe鈥揳rea compensation. With adequate heat-
sinking it can deliver output currents in excess of 1.0 ampere. Although designed primarily as a fixed
voltage regulator, this device can be used with external components to obtain adjustable voltages and
currents.
Features:
D
Output Current in Excess of 1.0 Ampere
D
No External Components Reguired
D
Internal Thermal Overload Protection
D
Internal Short鈥揅ircuit Current Limiting
D
Output Transistor Safe鈥揂rea Compensation
Absolute Maximum Ratings:
(T
A
= +25擄C unless otherwise specified)
Input Voltage, V
in
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35Vdc
Power Dissipation (T
A
= +25擄C), P
D
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Internally Limited
Derate above +25擄C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15.4mW/擄C
Power Dissipation (T
C
= +25擄C), P
D
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Internally Limited
Derate above +75擄C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200mW/擄C
Thermal Resistance, Junction鈥搕o鈥揂mbient, R
thJA
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65擄C/W
Thermal Resistance, Junction鈥搕o鈥揅ase, R
thJC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5擄C/W
Operating Junction Temperature Range, T
J
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +150擄C
Storage Junction Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +150擄C
Electrical Characteristics:
(V
in
= 23V, I
O
= 500mA, T
J
= 0擄 to +125擄C unless otherwise specified)
Parameter
Output Voltage
Symbol
V
O
Reg
line
Reg
load
T
J
= +25擄C
5mA
鈮?/div>
I
O
鈮?/div>
1A, P
O
鈮?/div>
15W, 17.5V
鈮?/div>
V
in
鈮?/div>
30V
Line Regulation
T
J
= +25擄C, Note 1
T
J
= +25擄C, Note 1
17.5V
鈮?/div>
V
in
鈮?/div>
30V
20V
鈮?/div>
V
in
鈮?/div>
26V
Load Regulation
5mA
鈮?/div>
I
O
鈮?/div>
1.5A
250mA
鈮?/div>
I
O
鈮?/div>
750mA
Test Conditions
Min
14.4
Typ
15.0
Max
15.6
Unit
V
V
mV
mV
mV
mV
14.25 15.0 15.75
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
13
6
52
20
300
150
300
150
Note 1. Load and line regulation are specified at constant junction temperature. Changes in V
O
due
to heating effects must be taken into account separately. Pulse testing with low duty cycle
is used.
