NTE950/NTE951/NTE977
Integrated Circuit
Positive 3 Terminal Voltage Regulator, 100mA
Description:
The NTE950, NTE951, and NTE977 are positive 3鈥搕erminal voltage regulators in available in a TO92
type package. With adequate heat sinking these regulators can deliver 100mA output current. Cur-
rent limiting is included to limit peak output current to safe value. Safe area protection for the output
transistors is provided to limit internal power dissipation. If internal power dissipation becomes too
high for the heat sinking provided, the thermal shutdown circuit takes over preventing the IC from
overheating.
When used as a zener diode/resistor combination replacement, these devices usually result in an ef-
fective output impedance improvement of two orders of magnitude, and lower quiescent current.
These regulators can provide local on card regulation, eliminating the distribution problems
associated with single point regulation. Typical applications include use in logic systems, instrumen-
tation, HiFi, and other solid state electronic equipment. Although designed primarily as fixed voltage
regulators these devices can be used with external components to obtain adjustment voltages and
currents.
Features:
D
Output Voltage Tolerances of
鹵5%
over the Temperature Range
D
Output Current of 100mA
D
Internal Thermal Overload Protection
D
Output Transistor Safe Area Protection
D
Internal Short Circuit Current Limit
Absolute Maximum Ratings:
Output Voltage, V
OUT
NTE977 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5V
NTE950 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12V
NTE951 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15V
Input Voltage, V
IN
NTE977 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30V
NTE950, NTE951 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35V
Internal Power Dissipation (Note 1), P
D
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Internally Limited
Operating Temperature Range, T
opr
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0擄C to +70擄C
Maximum Junction Temperature, T
J
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +125擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄C to +150擄C
Lead Temperature (Soldering, 10 sec), T
L
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +260擄C
Note 1. Thermal resistance is typically +60擄C/W junction to case, +232擄C/W junction to ambient, and
+88鈦凜/W junction to ambient at 400ft min of air. The maximum junction temperature shall
not exceed +125擄C on Electrical parameters.
