NTE708
Integrated Circuit
TV/FM Sound IF Amplifier
Features:
D
Greatly Simplifier FM Demodulator Alignment
D
Excellent Performance at V+ = 8V
Absolute Maximum Ratings:
(T
A
= +25擄C unless otherwise specified)
Power Supply Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16V
Peak Input Voltage (Pin4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.5V
Power Dissipation (T
A
= +25擄C), P
D
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 625mW
Derate Above 25擄C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5mW/擄C
Operating Ambient Temperature Range, T
opr
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0擄 to +75擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +150擄C
Electrical Characteristics:
(V+ = 12V, T
A
= +25擄C unless otherwise specified)
Parameter
Drain Current
Pin
13
V+ = 8V
V+ = 12V
Amplifier Input Reference Voltage
Detector Input Reference Voltage
Amplifier High Level Output Voltage
Amplifier Low Level Output Voltage
Detector Output Voltage
6
2
10
9
1
V+ = 8V
V+ = 12V
Amplifier Input Resistance
Amplifier Input Capacitance
Detector Input Resistance
Detector Input Capaciance
Amplifier Output Resistance
Detector Output Resistance
De鈥揈mphasis Resistance
4
4
12
12
10
1
14
Test Conditions
Min
10
鈥?/div>
鈥?/div>
鈥?/div>
1.25
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Typ
12
15
1.45
3.65
1.45
0.145
3.7
5.4
5.0
11
70
2.7
60
200
8.8
Max
19
21
鈥?/div>
鈥?/div>
1.65
0.2
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Unit
mA
mA
V
V
V
V
V
V
