NTE7077
Integrated Circuit
TV Fixed Voltage Regulator
110V
鹵0.8V,
1A
Absolute Maximum Ratings:
Maximum Peak Input Voltage, V
IN
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200V
Maximum Output Current, I
O
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1A
Power Dissipation (T
C
= +100擄C), P
D
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27W
Power Transistor Junction Temperature, T
J
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +150擄C
Operating Temperature Range (Case Temperature, Note 1), T
opr
. . . . . . . . . . . . . . . 鈥?0擄 to +125擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?0擄 to +125擄C
Note 1. Recommended Operating Temperature: T
opr
= +100擄C
Electrical Characteristics:
(T
A
= +25擄C unless otherwise specified)
Parameter
Output Voltage
Line Regulation
Load Regulation
Output Voltage Temperature
Coefficient
Input Output Saturation Voltage
Input Output Breakdown Voltage
DC Current Gain
Power Transistor Thermal
Resistance
Input Output Leakage Current
Output Base Reverse Current
Capacity (Between Emitter鈥揃ase)
V
EC(sat)
V
CEO
h
FE
R
螛JC
I
CEO
I
EB(S/B)
Symbol
V
O
Test Conditions
V
IN
= 134V, I
O
= 500mA,
I
IN
= 5.9mA, Note 2
Min
Typ
Max
Unit
V
V
V
mV/擄C
V
V
擄C/W
碌A(chǔ)
mA
109.2 110.0 110.8
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
200
1500
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鹵0
鈥?/div>
鈥?/div>
鈥?/div>
1.8
鈥?/div>
鈥?/div>
鈭?.4
鈭?.5
鈥?/div>
1.5
鈥?/div>
6500
鈥?/div>
100
300
Reg
LINE
V
IN
= 125V to 150V, I
O
= 500mA
Reg
LOAD
V
IN
= 134V, I
O
= 250mA to 500mA
V
IN
= 134V, I
O
= 500mA,
T
C
= 鈥?0擄 to +100擄C
I
C
= 1A, I
B
= 10mA
I
CEO
= 10mA, I
B
= 0
I
C
= 1A, V
CE
= 4V
Between Junction and Case
V
CE
(Pin3, Pin4) = 200V,
Pin1, Pin2, Pin5 Open
t = 65ms
Note 2. The fixed output voltage is to be measured 5 seconds after the power switch is turned on.
