NTE6082
Silicon Schottky Barrier Rectifier
Description:
The NTE6082 is a silicon switchmode power rectifier using the Schottky Barrier principle with a platinum
barrier metal.
Features:
D
Guardiring for Stress Protection
D
Low Forward Voltage
D
+150擄C Operating Junction Temperature
Maximum and Electrical Ratings:
(T
A
= +25擄C unless otherwise specified. Resistive or inductive
load. For capacitive or inductive load, derate current by 20%)
Maximum Peak Repetitive Reverse Voltage, V
RRM
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60V
Maximum Working Peak Reverse Voltage, V
RWM
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60V
Maximum DC Blocking Voltage, V
R
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60V
Maximum Average Rectified Forward Current (T
C
= +125擄C), I
F(AV)
. . . . . . . . . . . . . . . . . . . . . . . 16A
Peak Repetitive Forward Current (V
R
= 60V, Square Wave, 20kHz, T
C
= +125擄C), I
FRM
. . . . . 32A
Non鈥揜epetitive Peak Surge Current, I
FSM
(8.3ms single half sinewave superimposed on rated load) . . . . . . . . . . . . . . . . . . . . . . . . 150A
Peak Repetitive Reverse Surge Current (2.0碌s, 1.0kHz), I
RRM
. . . . . . . . . . . . . . . . . . . . . . . . 500mA
Operating Junction Temperature Range, T
J
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +150擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +150擄C
Voltage Rate of Change (V
R
= 60V), dv/dt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1000V/碌s
Maximum Thermal Resistance, Junction鈥搕o鈥揅ase, R
thJC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3擄/W
Maximum Instantaneous Forward Voltage (Per Leg, I
F
= 16A), V
F
T
C
= +125擄C (Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.65V
T
C
= +25擄C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.75V
Maximum Instantaneous Reverse Current (Rated DC Voltage), I
R
T
C
= +125擄C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50mA
T
C
= +25擄C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1mA
Note 1. Pulse Test: Pulse Width = 300碌s, Duty Cycle
