NTE2953
MOSFET
N鈥揅hannel, Enhancement Mode
High Speed Switch
Applications:
D
Motor Control
D
Lamp Control
D
Solenoid Control
D
DC鈥揇C Converter
Absolute Maximum Ratings:
(T
C
= +25擄C unless otherwise specified)
Drain鈥揝ource Voltage (V
GS
= 0V), V
DSS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60V
Gate鈥揝ource Voltage (V
DS
= 0V), V
GS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
鹵20V
Drain Current, I
D
Continuous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70A
Pulsed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280A
Avalanche Drain Current (Pulsed, L = 100碌H), I
DA
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70A
Source Current, I
S
Continuous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70A
Pulsed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280A
Maximum Power Dissipation, P
D
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35W
Channel Temperature Range, T
ch
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +150擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +150擄C
Thermal Resistance, Channel鈥搕o鈥揅ase, R
th(ch鈥揷)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.57擄C/W
Isolation Voltage, V
ISO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2000V
Electrical Characteristics:
(T
ch
= +25擄C unless otherwise specified)
Parameter
Drain鈥揝ource Breakdown Voltage
Gate鈥揝ource Leakage
Zero Gate Voltage Drain Current
Gate Threshold Voltage
Static Drain鈥揝ource ON Resistance
Drain鈥揝ource On鈥揝tate Voltage
Forward Transfer Admittance
Symbol
Test Conditions
V
GS
=
鹵20V,
V
DS
= 0V
V
DS
= 60V, V
GS
= 0
V
DS
= 10V, I
D
= 1mA
V
GS
= 10V, I
D
= 35A
V
GS
= 10V, I
D
= 35A
V
GS
= 10V, I
D
= 35A
Min
60
鈥?/div>
鈥?/div>
2.0
鈥?/div>
鈥?/div>
50
Typ
鈥?/div>
鈥?/div>
鈥?/div>
3.0
5.7
Max
鈥?/div>
鹵0.1
0.1
4.0
7.5
Unit
V
碌A(chǔ)
mA
V
m鈩?/div>
V
S
V
(BR)DSS
V
DS
= 0V, I
D
= 1mA
I
GSS
I
DSS
V
GS(th)
R
DS(on)
V
DS(on)
|y
fs
|
0.200 0.263
70
鈥?/div>
