NTE267
Silicon NPN Transistor
High Gain Darlington Power Amp, Switch
Features:
D
Forward Current Transfer Ratio: h
FE
= 90,000 min.
D
Free鈥揂ir Power Dissipation: 1.33W @ T
A
= +50擄C
D
Hard Solder Mountdown
Applications:
D
Driver
D
Regulator
D
Audio Output
D
Relay Substitute
D
Touch Switch
D
D
D
D
Oscillator
IC Driver
Servo Amplifier
Capacitor Multiplier
Absolute Maximum Ratings:
(T
A
= +25擄C, unless otherwise specified)
Collector to Emitter, V
CEO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30V
Emitter to Base, V
EBO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13V
Collector to Emitter, V
CES
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30V
Collector Current, I
C
Continuous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 500mA
Peak . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1A
Power Dissipation, P
T
Tab at +25擄C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.25W
Free Air at +50擄C
w
/Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.33W
Thermal Resistance, Junction to Case (Note 1), R
thJC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20擄C/W
Thermal Resistance, Junction to Ambient (Note 1), R
thJA
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 75擄C/W
Operating Junction Temperature Range, T
J
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +150擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +150擄C
Lead Temperature (During Soldering, 1/16鈥?/div>
鹵1/32鈥?/div>
from case, 10sec max), T
L
. . . . . . . . . . +260擄C
Note 1. Tab temperature is measured on center of tab, 1/16鈥?from plastic body.
