NTE2598
Silicon NPN Transistor
High Voltage, High Current Switch
Features:
D
High Breakdown Voltage, Reliability
D
fast Switching Speed
D
Wide ASO
Absolute Maximum Ratings:
(T
A
= +25擄C unless otherwise specified)
Collector鈥揃ase Voltage, V
CBO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1100V
Collector鈥揈mitter Voltage, V
CEO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 800V
Emitter鈥揃ase Voltage, V
EBO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7V
Collector Current, I
C
Continuous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25A
Peak (Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60A
Base Current. I
B
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12A
Collector Power Dissipation (T
C
= +25擄C), P
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300W
Operating Junction Temperature, T
J
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +150擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +150擄C
Note 1. Pulse Test: Pulse Width
鈮?/div>
300碌s, Duty Cycle
鈮?/div>
10%.
Electrical Characteristics:
(T
A
= +25擄C unless otherwise specified)
Parameter
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain
Gain鈥揃andwidth Product
Output Capacitance
Collector鈥揈mitter Saturation Voltage
Base鈥揈mitter Saturation Voltage
Symbol
I
CBO
I
EBO
h
FE
f
T
C
ob
V
CE(sat)
V
BE(sat)
Test Conditions
V
CB
= 800V, I
E
= 0
V
EB
= 5V, I
C
= 0
V
CE
= 5V, I
C
= 1.6A
V
CE
= 5V, I
C
= 8A
V
CE
= 10V, I
C
= 1.6A
V
CB
= 10V, f = 1MHz
I
C
= 12A, I
B
= 2.4A
I
C
= 12A, I
B
= 2.4A
Min
鈥?/div>
鈥?/div>
15
8
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Typ
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
15
470
