NTE2576 (NPN) & NTE2577 (PNP)
Silicon Complementary Transistors
Audio Output Driver
Absolute Maximum Ratings:
(T
A
= +25擄C unless otherwise specified)
Collector鈥揃ase Voltage, V
CBO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180V
Collector鈥揈mitter Voltage, V
CEO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180V
Emitter鈥揃ase Voltage, V
EBO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6V
Collector Current, I
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2A
Base Current, I
B
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1A
Power Dissipation (T
C
= +25擄C), P
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20W
Operating Junction Temperature, T
J
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +150擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +150擄C
Electrical Characteristics:
(T
A
= +25擄C unless otherwise specified)
Parameter
Collector Cutoff Current
Emitter Cutoff Current
Collector鈥揈mitter Breakdown Voltage
DC Current Gain
Collector鈥揈mitter Saturation Voltage
Transition Frequency
Output Capacitance
Symbol
I
CBO
I
EBO
h
FE
V
CE(sat)
f
T
C
ob
Test Conditions
V
CB
= 180V
V
EB
= 6V
V
CE
= 10V, I
C
= 700mA
I
C
= 700mA, I
B
= 70mA
V
CE
= 12V, I
E
= 700mA
V
CB
= 10V, f = 1MHz
Min
鈥?/div>
鈥?/div>
180
60
鈥?/div>
鈥?/div>
鈥?/div>
Typ
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
60
30
Max
10
10
鈥?/div>
240
1.0
鈥?/div>
鈥?/div>
V
MHz
pF
Unit
碌A(chǔ)
碌A(chǔ)
V
V
(BR)CEO
I
C
= 10mA
