NTE2554 (NPN) & NTE2555 (PNP)
Silicon Complementary Transistors
Darlington Driver
Applications:
D
Industrial Equipment
D
Printers
D
Typewriters
D
Sewing Machines
D
Recorders
D
Computers
D
Igniters
D
D
D
D
D
D
D
Car Coolers
Projectors
Players
Stereos
Home Appliances
Audio Equipment
ECRs
Absolute Maximum Ratings:
(T
A
= +25擄C unless otherwise specified)
Collector鈥揃ase Voltage, V
CBO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70V
Collector鈥揈mitter Voltage, V
CEO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60V
Emitter鈥揃ase Voltage, V
EBO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6V
Collector Current, I
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7A
Collector Power Dissipation (T
C
= +25擄C), P
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35W
Operating Junction Temperature, T
J
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +150擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +150擄C
Electrical Characteristics:
(T
A
= +25擄C unless otherwise specified)
Parameter
DC Current Gain
Collector鈥揈mitter Saturation Voltage
Transition Frequency
Symbol
h
FE
V
CE(sat)
f
T
Test Conditions
V
CE
= 2V, I
C
= 3.5A
I
C
= 3.5A, I
B
= 7mA
Min
2000
鈥?/div>
