NTE2551 (NPN) & NTE2552 (PNP)
Silicon Complementary Transistors
Darlington Driver, Switch
Features:
D
High DC Current Gain
D
Low Saturation Voltage
D
High Current Capacity and Wide ASO
D
Isolated TO220 Type Package
Applications:
D
Motor Drivers
D
Printer Hammer Drivers
D
Relay Drivers
D
Voltage Regulator Control
Absolute Maximum Ratings:
(T
A
= +25擄C unless otherwise specified)
Collector鈥揃ase Voltage, V
CBO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70V
Collector鈥揈mitter Voltage, V
CEO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60V
Emitter鈥揃ase Voltage, V
EBO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6V
Collector Current, I
C
Continuous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10A
Peak . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15A
Collector Power Dissipation, P
C
T
A
= +25擄C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2W
T
C
= +25擄C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30W
Operating Junction Temperature, T
J
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +150擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +150擄C
Electrical Characteristics:
(T
A
= +25擄C unless otherwise specified)
Parameter
Collector Cut鈥揙ff Current
Emitter Cut鈥揙ff Current
DC Current Gain
Gain鈥揃andwidth Product
Collector鈥揈mitter Saturation Voltage
Base鈥揈mitter Saturation Voltage
Collector鈥揃ase Breakdown Voltage
Symbol
I
CBO
I
EBO
h
FE (1)
f
T
V
BE(sat)
Test Conditions
V
CB
= 40V, I
E
= 0
V
EB
= 5V, I
C
= 0
V
CE
= 2V, I
C
= 5A
V
CE
= 5V, I
C
= 5A
I
C
= 5A, I
B
= 10mA
Min
鈥?/div>
鈥?/div>
2000
鈥?/div>
鈥?/div>
鈥?/div>
70
60
Typ
鈥?/div>
鈥?/div>
500
0
20
0.9
鈥?/div>
鈥?/div>
鈥?/div>
Max
0.1
3.0
鈥?/div>
鈥?/div>
1.5
2.0
鈥?/div>
鈥?/div>
MHz
V
V
V
V
Unit
mA
mA
V
CE(sat)
I
C
= 5A, I
B
= 10mA
V
(BR)CBO
I
C
= 5mA, I
E
= 0
Collector鈥揈mitter Breakdown Voltage V
(BR)CEO
I
C
= 50mA, R
BE
=
鈭?/div>
