NTE2322
Silicon PNP Transistor
Quad, General Purpose
Absolute Maximum Ratings:
Collector鈥揈mitter Voltage, V
CEO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40V
Collector鈥揃ase Voltage, V
CBO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60V
Emitter鈥揃ase Voltage, V
EBO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5V
Continuous Collector Current, I
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 600mA
Total Device Dissipation (T
A
= +25擄C, Each Transistor), P
D
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.65W
Derate Above 25擄C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.5mW/擄C
Total Device Dissipation (T
A
= +25擄C, Total Device), P
D
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.9W
Derate Above 25擄C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19mW/擄C
Operating Junction Temperature Range, T
J
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +125擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +125擄C
Thermal Reistance, Junction鈥搕o鈥揂mbient, R
thJA
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66擄C/W
Electrical Characteristics:
(T
A
= +25擄C unless otherwise specified)
Parameter
OFF Characteristics
Collector鈥揈mitter Breakdown Voltage
Collector鈥揃ase Breakdown Voltage
Emitter鈥揃ase Breakdown Voltage
Collector Cutoff Current
Emitter Cutoff Current
ON Characteristics
(Note 1)
DC Current Gain
h
FE
V
CE
= 10V, I
C
= 10mA
V
CE
= 10V, I
C
= 150mA
V
CE
= 10V, I
C
= 300mA
Collector鈥揈mitter Saturation Voltage
V
CE(sat)
V
BE(sat)
I
C
= 150mA, I
B
= 15mA
I
C
= 300mA, I
B
= 30mA
Base鈥揈mitter Saturation Voltage
I
C
= 150mA, I
B
= 15mA
I
C
= 300mA, I
B
= 30mA
75
100
30
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
0.4
1.6
1.5
2.6
V
V
V
V
V
(BR)CEO
V
(BR)CBO
V
(BR)EBO
I
CBO
I
EBO
I
C
= 10mA, I
B
= 0, Note 1
I
C
= 10碌A, I
E
= 0
I
E
= 10碌A, I
C
= 0
V
CB
= 30V, I
E
= 0
V
EB
= 3V, I
E
= 0
40
60
5
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
50
50
V
V
V
nA
nA
Symbol
Test Conditions
Min
Typ
Max
Unit
Note 1. Pulse test: Pulse Width
鈮?/div>
300碌s, Duty Cycle
next
