NTE2316
Silicon NPN Transistor
Fast Switching Power Darlington
Description:
The NTE2317 is an NPN transistor in a monolithic Darlington configuration mounted in a TO218 type
package designed for use in automotive ignition applications and inverter circuits for motor controls.
Applications:
D
Automotive Ignition Applications
D
Invert Circuits for Motor Controls
Absolute Maximum Ratings:
Collector鈥揈mitter Voltage (V
BE
= 0), V
CES
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 500V
Collector鈥揈mitter Voltage (I
B
= 0), V
CEO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 450V
Emitter鈥揃ase Voltage (I
C
= 0), V
EBO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5V
Collector Current, I
C
Continuous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10A
Peak . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15A
Continuous Base Current, I
B
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5A
Total Power Dissipation (T
C
鈮?/div>
+25擄C), P
tot
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105W
Maximum Operating Junction Temperature, T
J
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +150擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?0擄 to +150擄C
Thermal Resistance, Junction鈥搕o鈥揅ase, R
thJC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2擄C/W
Electrical Characteristics:
(T
C
= +25擄C unless otherwise specified)
Parameter
Collector Cutoff Current
Symbol
I
CES
I
CEO
Emitter Cutoff Current
I
EBO
Test Conditions
T
J
= +25擄C
T
J
= +125擄C
V
CE
= 500V,
V
BE
= 0
Min
450
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Typ
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Max
鈥?/div>
1
5
1
20
Unit
V
mA
mA
mA
mA
Collector鈥揈mitter Sustaining Voltage V
CEO(sus)
I
C
= 100mA, I
B
= 0, Note 1
V
CE
= 450V, I
B
= 0
I
C
= 0, V
EB
= 5V
Note 1. Pulse Test: Pulse Width = 300碌s, Duty Cycle = 1.5%.
