NTE1902
Integrated Circuit
3 Terminal Positive Voltage Regulator
9V, 100mA
Features:
D
Output Current up to 100mA
D
No External Components
D
Internal Thermal Overload Protection
D
Internal Short鈥揅ircuit Current Limiting
D
Output Voltage Tolerances of
鹵5%
over the Temperature Range
Absolute Maximum Ratings:
Input Voltage, V
IN
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35V
Internal Power Dissipation, P
D
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Internally Limited
Operating Junction Temperature Range, T
J
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0擄 to +125擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +150擄C
Lead Temperature (During Soldering, 10sec), T
L
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +260擄C
Electrical Characteristics:
(V
OUT
= 9V, V
IN
= 15V, 0擄
鈮?/div>
T
J
鈮?/div>
+125擄C, I
O
= 40mA, C
IN
= 0.33碌F,
C
OUT
= 0.1碌F, Note 1 unless otherwise specified)
Parameter
Output Voltage
Symbol
V
O
Reg
Line
Test Conditions
T
J
= +25擄C
1mA
鈮?/div>
I
O
鈮?/div>
70mA, 11.5V
鈮?/div>
V
IN
鈮?/div>
24V
Line Regulation
T
J
= +25擄C 11.5V
鈮?/div>
V
IN
鈮?/div>
24V
13V
鈮?/div>
V
IN
鈮?/div>
24V
Load Regulation
Reg
Load
T
J
= +25擄C 1mA
鈮?/div>
I
O
鈮?/div>
100mA
1mA
鈮?/div>
I
O
鈮?/div>
40mA
Quiescent Current
Quiescent Current Change
I
B
I
B
V
N
RR
V
DO
I
pk
/I
OS
With line, 11.5V
鈮?/div>
V
IN
鈮?/div>
24V
With load, 1mA
鈮?/div>
I
O
鈮?/div>
40mA
Output Noise Voltage
Temperature Coefficient of V
OUT
Ripple Rejection
Dropout Voltage
Peak Output/Short Circuit Current
T
A
= +25擄C, f = 10Hz to 10kHz
I
OUT
= 5mA
T
J
= +25擄C, 15V
鈮?/div>
V
IN
鈮?/div>
25V, f = 120Hz
T
J
= +25擄C
T
J
= +25擄C
Min
8.64
8.55
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
38
鈥?/div>
鈥?/div>
Typ
9.00
9.00
90
100
20
10
2.1
鈥?/div>
鈥?/div>
70
鈥?.9
44
1.4
140
Max
9.36
9.45
200
150
90
45
5.5
1.5
0.1
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Unit
V
V
mV
mV
mV
mV
mA
mA
mA
碌V
mV/擄C
dB
V
mA
Note 1. The maximum steady state usable output current and input voltage ar very dependent on
the heat sink and/or lead length of the package. The data above represents pulse test condi-
tions with junction temperatures as indicated at the initiation of the test.
