NTE1716
Integrated Circuit
Reversible Motor Driver for VCR
Features:
D
Supply Voltage Range: 6V to 18V
D
Power Dissipation: 2200mW
D
Output Motor Driving Current up to 1600mA
D
Two Control Logic Inputs Allow Switching of Three Output States:
Forward
Reverse
Braking
D
Low Standby Current
D
Adjustable Output Voltage Enables Motor Speed Control Using Control Pin Voltage
D
Interfaces with CMOS Devices
D
Built鈥揑n Components to Absorb Motor Rush Currents
Applications:
D
Video Tape Recorders
D
Cassette Tape Recorders
Absolute Maximum Ratings:
(T
A
= +25擄C unless otherwise specified)
Supply Voltage, V
CC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18V
Power Dissipation (T
A
= +25擄C), P
D
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2200mW
Derate Above +25擄C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22mW/擄C
Output Current (Pulse Width = 500碌s, Duty Cycle = 1%), I
O
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6A
Input Voltage, V
IN
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?.3V to V
CC
Operating Temperature Range, T
opr
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?0擄 to +75擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +125擄C
Recommended Operating Conditions:
(T
A
= +25擄C unless otherwise specified)
Parameter
Supply Voltage 1 (Logic)
Supply Voltage 2 (Motor)
Symbol
V
CC1
V
CC2
Test Conditions
Min
6
6
Typ
1
2
3
