NTE1466
Integrated Circuit
Preamp
w
/ALC Transistors
Features:
D
Pre鈥揂mplifier (Recording or Playback) with ALC Transistors for Tape Recorder
D
Low Noise: V
NI
= 1.3碌V
rms
(Typ)
D
Wide ALC Range
D
Operates from a Wide Range of Power Supplies: V
CC
opr = 3V to 15V
Absolute Maximum Ratings:
(T
A
= +25擄C unless otherwise specified)
Supply Voltage, V
CC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15V
Power Dissipation, P
D
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200mW
Derate Above 25擄C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2mW/擄C
Operating Temperature Range, T
opr
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +75擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +125擄C
Electrical Characteristics:
(V
CC
= 5V, T
A
= +25擄C unless otherwise specified)
Parameter
Supply Current
Voltage Gain (Open Loop)
Voltage Gain (Closed Loop)
Maximum Output Voltage
Equivalent Input Noise Voltage
Input Resistance
Saturation Voltage, Q
5
Symbol
I
CC
G
VO
G
V
V
OM
V
NI
R
IN
V
6(ON)
Test Conditions
V
IN
= 0, ALC off
V
IN
= 鈥?0dBm f = 1kHz
V
OUT
= 0.7V
rms
f = 1kHz, Note 1
f = 1kHz (below), THD = 1% Max
R
g
= 2.2k鈩? NAB (Compensated), 1kHz Gain
Converted with G
V
(1kHz)
f = 1kHz
Min
鈥?/div>
67
33
0.7
鈥?/div>
鈥?/div>
鈥?/div>
Typ
1.3
69
35
0.9
1.3
150
60
Max
1.75
鈥?/div>
37
鈥?/div>
2.5
鈥?/div>
100
Unit
mA
dB
dB
V
rms
碌V
rms
k鈩?/div>
mV
Note 1. In regard to the voltage gain (closed loop voltage) value, it is possible to be classified.
