NTE1442
Integrated Circuit
Balance Modulator
Features:
D
Broad Band (10MHz), Good Carrier Suppression
D
Carrier Suppression Within 鈥?0dB (10mV
rms
to 1V
rms
Output Signal)
Absolute Maximum Ratings:
(T
A
= +25擄C unless otherwise specified)
Supply Voltage (V
8鈥?1
), V
CC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14.4V
Supply Current, I
CC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15mA
Power Dissipation, P
D
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 400mW
Operating Temperature Range, T
opr
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?0擄 to +70擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +150擄C
Electrical Characteristics:
(T
A
= +25擄C unless otherwise specified)
Parameter
DC Current Gain
Output Offset Current (1)
Output Offset Current (2)
Output Offset Current (3)
Output Offset Current (4)
Symbol
h
FE
(T8)
h
FE
(T7)
I
8鈥?/div>
I
7
I
8鈥?/div>
I
7
I
8鈥?/div>
I
7
I
8鈥?/div>
I
7
Test Conditions
Min
40
40
鈥?00
鈥?00
鈥?00
鈥?00
Typ
100
100
0
0
0
0
Max
300
300
100
100
100
100
碌A
碌A
碌A
碌A
Unit
1
2
