NTE1358
Integrated Circuit
Module, AF PO, 50W,
Dual Power Supply
Absolute Maximum Ratings:
(T
A
= +25擄C unless otherwise specified)
Maximum Supply Voltage, V
CC
max . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
鹵53V
Operating Junction Temperature, T
J
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +150擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?0擄 to +105擄C
Thermal Resistance, Junction鈥搕o鈥揅ase, R
thJC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8擄C/W
Available Time for Load Shorted (V
CC
=
鹵36V,
R
L
= 8鈩? f = 50Hz, P
O
= 50W), t
s
. . . . . . . . . . . 2sec
Recommended Operating Conditions:
(T
A
= +25擄C unless otherwise specified)
Recommended Supply Voltage, V
CC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
鹵23V
Load Resistance, R
L
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8鈩?/div>
Electrical Characteristics:
(T
A
= +25擄C, V
CC
=
鹵36V,
R
L
= 8鈩?(Non鈥揑nductive Load), R
g
= 600鈩?
V
G
= 26.3dB unless otherwise specified)
Parameter
Quiescent Current
Output Power
Symbol
I
CCO
P
O
THD
R
E
V
CC
=
鹵43V
THD = 0.02%, f = 20Hz to 20kHz
V
CC
=
鹵31V,
THD = 0.03%, f = 1kHz, R
L
= 4鈩?/div>
Total Harmonic Distortion
Emitter Resistance
P
O
= 1 to 50W, f = 20Hz to 20kHz
Test Conditions
Min
20
50
55
鈥?/div>
0.18
Typ
40
鈥?/div>
鈥?/div>
鈥?/div>
0.22
Max
80
鈥?/div>
鈥?/div>
0.02
0.30
Unit
mA
W
W
%
鈩?/div>
Note 1. For power supply at the time of test, use a constant鈥搗oltage power supply unless otherwise
specified.
