NTE1104
Integrated Circuit
Wide and Narrow Band Amp,
FM/IF Limiter
Applications:
D
For FM IF Amplifier
D
For TV SIF Amplifier
Absolute Maximum Ratings:
(T
A
= +25擄C unless otherwise specified)
Supply Voltage, V
CC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15V
Output Voltage, V
OUT
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24V
Input Voltage (Between Pin1 and Pin2), V
IN
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
鹵15V
Power Dissipation, P
D
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 400mW
Derate Above 25擄C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3mW/擄C
Operating Temperature Range (V
CC
= 12V), T
opr
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?0 to +75擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5 to +125擄C
Electrical Characteristics:
(T
A
= +25擄C unless otherwise specified)
Parameter
Supply Current
Power Dissipation
Voltage Gain
Input Impedance
Parallel Input Resistance
Parallel Input Capacitance
Output Impedance
Parallel Input Resistance
Parallel Input Capacitance
Forward Transfer Admittance
Reverse Transfer Admittance
Symbol
I
CC
P
D
G
V
r
ip
c
ip
r
op
c
op
y
f
y
r
Test Conditions
V
CC
= 12V
V
CC
= 9V
V
CC
= 12V
V
CC
= 9V
V
CC
= 12V, R
g
= 50鈩? R
L
= 1k鈩?/div>
V
CC
= 12V, f = 10.7MHz
Min
5.3
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Typ
9.5
6.5
114
59
26.5
35
8.0
80
3.0
30
2.0
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Max
14.0
Unit
mA
mA
mW
mW
dB
