NM9715CV Datasheet

IC型號：
NM9715CV
PDF描述：
PCI Dual 1284 Printer Ports
文件大?。?/label>
100.79KB
PDF頁數：
17頁
芯片廠家：
ETC

閱覽下載糾錯 0

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17

Nm9715

PCI Dual 1284 Printer Ports

Features

鈥?/div>

Single 5V operation

鈥?/div>

Low power

鈥?/div>

Pin-to-pin compatible to Nm9705

鈥?/div>

PCI compatible dual 1284 printer port

鈥?/div>

Multi-mode compatible controller (SPP, PS2, EPP,

ECP)

鈥?/div>

Fast data rates up to 1.5 Mbytes/s (parallel port)

鈥?/div>

Re-map function for legacy ports

鈥?/div>

16-byte FIFO (parallel)

鈥?/div>

Microsoft Windows compatible registers

鈥?/div>

Software programmable mode selects

鈥?/div>

128-pin QFP package

Applications

鈥?/div>

Printer server

鈥?/div>

Portable backup units

鈥?/div>

Printer interface

鈥?/div>

Add-on I/O cards

Application Notes

鈥?/div>

AN-9715

General Description

The Nm9715 is a dual 1284 parallel port controller with

PCI bus interface. Nm9715 fully supports the existing

Centronics printer interface as well as PS/2, EPP, and

ECP modes.

The Nm9715 is ideally suited for PC applications, such

as high speed parallel ports. The Nm9715 is available

in a 128-pin QFP package. It is fabricated using an ad-

vanced submicron CMOS process to achieve low drain

power and high speed requirements.

Ordering Information

Commercial Grade

Nm9715CV

128-QFP

0擄 C to +70擄 C

MosChip Semiconductor

鈾?/div>

3335 Kifer Rd, Santa Clara, CA 95051

鈾?/div>

Tel (408) 737-7141

鈾?/div>

Fax (408) 737-7708
