Printheads

High speed thermal printhead

(8 dots / mm)

NM2004-UA10A

The NM2004-UA10A is a flat thin-film thermal printhead with a built-in heat history control function, suited for general

purpose compact printers as well as label printers with printing speeds up to 10 inch / second.

FApplications

Bar code label printers

Ticket printers

General purpose compact printers

FFeatures

1) Special glazed components for high speed, high quality printing.

2) Our heat history control circuit reduces the load on the printer to control heat

history.

3) Using a hard conductive film as a protective film on the heating element of-

fers excellent resistance to electrostatic damage.

FExternal

dimensions (Units: mm)

1
