NLSF308/D Datasheet

  • NLSF308/D

  • Quad 2-Input AND Gate

  • 6頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NLSF308
Quad Gate
2鈭捍nput AND
The NLSF308 is an advanced high speed CMOS 2鈭抜nput AND gate
fabricated with silicon gate CMOS technology. It achieves high speed
operation similar to equivalent Bipolar Schottky TTL while
maintaining CMOS low power dissipation.
The internal circuit is composed of three stages, including a buffer
output which provides high noise immunity and stable output. The
inputs tolerate voltages up to 7 V, allowing the interface of 5 V
systems to 3 V systems.
鈥?/div>
High Speed: t
PD
= 4.3 ns (Typ) at V
CC
= 5 V
鈥?/div>
Low Power Dissipation: I
CC
= 2
mA
(Max) at T
A
= 25擄C
鈥?/div>
High Noise Immunity: V
NIH
= V
NIL
= 28% V
CC
鈥?/div>
Power Down Protection Provided on Inputs
鈥?/div>
Balanced Propagation Delays
鈥?/div>
Designed for 2 V to 5.5 V Operating Range
鈥?/div>
Low Noise: V
OLP
= 0.8 V (Max)
鈥?/div>
Function Compatible with Other Standard Logic Families
鈥?/div>
QFN鈭?6 Package
鈥?/div>
Latchup Performance Exceeds 300 mA
鈥?/div>
ESD Performance: HBM > 2000 V; Machine Model > 200 V
鈥?/div>
Chip Complexity: 24 FETs or 6 Equivalent Gates
http://onsemi.com
MARKING
DIAGRAM
16
1
QFN鈭?6
MN SUFFIX
CASE 485G
NLSF
308
ALYW
(Top View)
A
WL, L
YY, Y
WW, W
= Assembly Location
= Wafer Lot
= Year
= Work Week
ORDERING INFORMATION
Device
NLSF308MN
NLSF308MNR2
Package
QFN鈭?6, 3x3
Shipping鈥?/div>
123 Units/Rail
QFN鈭?6, 3x3 3000/Tape & Reel
鈥燜or information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D.
漏
Semiconductor Components Industries, LLC, 2003
1
October, 2003 鈭?Rev. 1
Publication Order Number:
NLSF308/D
