NLAST4053
Analog Multiplexer/
Demultiplexer
TTL Compatible, Triple 2:1 Analog
Switch鈥揗ultiplexer Improved Process,
Sub鈥揗icron Silicon Gate CMOS
The NLAST4053 is an improved version of the MC14053 and
MC74HC4053 fabricated in sub鈥搈icron Silicon Gate CMOS
technology for lower R
DS(on)
resistance and improved linearity with
low current. This device may be operated either with a single supply or
dual supply up to
鹵3
V to pass a 6 V
PP
signal without coupling
capacitors.
When operating in single supply mode, it is only necessary to tie
V
EE
, pin 7 to ground. For dual supply operation, V
EE
is tied to a
negative voltage, not to exceed maximum ratings. Translation is
provided in the device, the Address and Inhibit pins are standard TTL
level compatible. For CMOS compatibility see NLAS4053. Pin for
pin compatible with all industry standard versions of 鈥?053.鈥?/div>
http://onsemi.com
MARKING DIAGRAMS
16
9
SO鈥?6
D SUFFIX
CASE 751B
NLAST4053
AWLYWW
1
8
16
9
NLAST
ALYW
TSSOP鈥?6
DT SUFFIX
CASE 948F
鈥?/div>
Improved R
DS(on)
Specifications
鈥?/div>
Pin for Pin Replacement for MAX4053 and MAX4053A
鈥?One Half the Resistance Operating at 5.0 Volts
鈥?/div>
Single or Dual Supply Operation
鈥?Single 3鈥? Volt Operation, or Dual
鹵3
Volt Operation
鈥?With V
CC
of 3.0 to 3.3 V, Device Can Interface with 1.8 V Logic,
鈥?/div>
No Translators Needed
鈥?Address and Inhibit Pins are Over鈥揤oltage Tolerant and May Be
鈥?/div>
Driven Up +6 V Regardless of V
CC
鈥?/div>
Address and Inhibit Pins are Standard TTL Compatible
鈥?Greatly Improved Noise Margin Over MAX4053 and MAX4053A
鈥?True TTL Compatibility V
IL
= 0.8 V, V
IH
= 2.0 V
鈥?/div>
Improved Linearity Over Standard HC4053 Devices
1
8
16
9
QSOP鈥?6
QS SUFFIX
CASE 492
A
L, WL
Y
W
NLAST
4053
ALYW
1
8
= Assembly Location
= Wafer Lot
= Year
= Work Week
鈥?/div>
Popular SOIC, and Space Saving TSSOP, and QSOP 16 Pin
Packages
ORDERING INFORMATION
Device
NLAST4053D
NLAST4053DR2
NLAST4053DT
NLAST4053DTR2
NLAST4053QS
NLAST4053QSR
Package
SO鈥?6
SO鈥?6
TSSOP鈥?6
TSSOP鈥?6
QSOP鈥?6
QSOP鈥?6
Shipping
48 Units/Rail
2500 Units/Reel
96 Units/Rail
2500 Units/Reel
98 Units/Rail
2500 Units/Reel
漏
Semiconductor Components Industries, LLC, 2002
1
June, 2002 鈥?Rev. 0
Publication Order Number:
NLAST4053/D
