NLAST4052/D Datasheet

  • NLAST4052/D

  • Analog Multiplexer/ Demultiplexer

  • 130.05KB

  • 16頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NLAST4052
Analog Multiplexer/
Demultiplexer
TTL Compatible, Double鈥揚ole, 4鈥揚osition
Plus Common Off
The NLAST4052 is an improved version of the MC14052 and
MC74HC4052 fabricated in sub鈥搈icron Silicon Gate CMOS
technology for lower R
DS(on)
resistance and improved linearity with
low current. This device may be operated either with a single supply or
dual supply up to
鹵3
V to pass a 6 V
PP
signal without coupling
capacitors.
When operating in single supply mode, it is only necessary to tie
V
EE
, pin 7 to ground. For dual supply operation, V
EE
is tied to a
negative voltage, not to exceed maximum ratings. Translation is
provided in the device, the Address and Inhibit pins are standard TTL
level compatible. For CMOS compatibility see NLAS4052. Pin for
pin compatible with all industry standard versions of 鈥?052.鈥?/div>
http://onsemi.com
MARKING DIAGRAMS
16
9
SO鈥?6
D SUFFIX
CASE 751B
NLAST4052
AWLYWW
1
8
16
9
鈥?/div>
Improved R
DS(on)
Specifications
鈥?/div>
Pin for Pin Replacement for MAX4052 and MAX4052A
鈥?One Half the Resistance Operating at 5.0 Volts
鈥?/div>
Single or Dual Supply Operation
鈥?Single 3鈥? Volt Operation, or Dual
鹵3
Volt Operation
鈥?With V
CC
of 3.0 to 3.3 V, Device Can Interface with 1.8 V Logic,
鈥?/div>
No Translators Needed
鈥?Address and Inhibit pins are Logic is Over鈥揤oltage Tolerant and
鈥?/div>
鈥?/div>
May Be Driven Up +6 V Regardless of V
CC
鈥?/div>
Address and Inhibit pins are Standard TTL Compatible
鈥?Greatly Improved Noise Margin Over MAX4052 and MAX4052A
鈥?True TTL Compatibility V
IL
= 0.8 V, V
IH
= 2.0 V
鈥?/div>
Improved Linearity Over Standard HC4052 Devices
NLAST
ALYW
TSSOP鈥?6
DT SUFFIX
CASE 948F
1
8
16
9
QSOP鈥?6
QS SUFFIX
CASE 492
A
L, WL
Y
W
NLAST
4052
ALYW
1
8
鈥?/div>
Popular SOIC, and Space Saving TSSOP, and QSOP 16 Pin
Packages
= Assembly Location
= Wafer Lot
= Year
= Work Week
ORDERING INFORMATION
Device
NLAST4052D
NLAST4052DR2
NLAST4052DT
NLAST4052DTR2
NLAST4052QS
NLAST4052QSR
Package
SO鈥?6
SO鈥?6
TSSOP鈥?6
TSSOP鈥?6
QSOP鈥?6
QSOP鈥?6
Shipping
48 Units/Rail
2500 Units/Reel
96 Units/Rail
2500 Units/Reel
98 Units/Rail
2500 Units/Reel
漏
Semiconductor Components Industries, LLC, 2002
1
June, 2002 鈥?Rev. 2
Publication Order Number:
NLAST4052/D
