NLAS4501
Analog Switch
The NLAS4501 is an analog switch manufactured in sub鈥搈icron
silicon鈥揼ate CMOS technology. It achieves very low R
ON
while
maintaining extremely low power dissipation. The device is a bilateral
switch suitable for switching either analog or digital signals, which may
vary from zero to full supply voltage.
The NLAS4501 is pin鈥揻or鈥損in compatible with the MAX4501. The
NLAS4501 can be used as a direct replacement for the MAX4501 in all
2.0 V to 5.5 V applications where a R
ON
performance improvement is
required.
The Enable pin is compatible with standard CMOS outputs when
supply voltage is nominal 5.0 Volts. It is also over鈥搗oltage tolerant,
making it a very useful logic level translator.
http://onsemi.com
MARKING
DIAGRAMS
SC鈥?8A / SOT鈥?53/SC鈥?0
DF SUFFIX
CASE 419A
V9
d
鈥?/div>
Guaranteed R
ON
of 32
W
at 5.5 V
鈥?/div>
Low Power Dissipation: I
CC
= 2
mA
鈥?/div>
Provides Voltage translation for many different voltage levels
3.3 to 5.0 Volts, Enable pin may go as high as +5.5 Volts
1.8 to 3.3 Volts
1.8 to 2.5 Volts
鈥?/div>
Improved version of MAX4501 (at any voltage between 2 and 5.5
Volts)
鈥?/div>
Chip Complexity: FETs 11
Pin 1
d = Date Code
TSOP鈥?/SOT鈥?3/SC鈥?9
DT SUFFIX
CASE 483
V9
d
Pin 1
d = Date Code
PIN ASSIGNMENT
1
2
COM
1
5
V+
3
4
NO
2
5
COM
NO
GND
ENABLE
V
CC
GND
3
4
ENABLE
FUNCTION TABLE
On/Off Enable Input
State of Analog Switch
Off
On
Figure 1. Pinout
(Top View)
L
H
ORDERING INFORMATION
See detailed ordering and shipping information on page 6 of
this data sheet.
漏
Semiconductor Components Industries, LLC, 2001
1
April, 2001 鈥?Rev. 1
Publication Order Number:
NLAS4501/D
