NLAS4051/D Datasheet

  • NLAS4051/D

  • Analog Multiplexer/Demultiplexer

  • 16頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NLAS4051
Analog Multiplexer/
Demultiplexer
TTL Compatible, Single鈥揚ole, 8鈥揚osition
Plus Common Off
The NLAS4051 is an improved version of the MC14051 and
MC74HC4051 fabricated in sub鈥搈icron Silicon Gate CMOS
technology for lower R
DS(on)
resistance and improved linearity with
low current. This device may be operated either with a single supply or
dual supply up to
鹵3
V to pass a 6 V
PP
signal without coupling
capacitors.
When operating in single supply mode, it is only necessary to tie
V
EE
, pin 7 to ground. For dual supply operation, V
EE
is tied to a
negative voltage, not to exceed maximum ratings.
http://onsemi.com
MARKING DIAGRAMS
16
9
SO鈥?6
D SUFFIX
CASE 751B
NLAS4051
AWLYWW
1
8
鈥?/div>
Improved R
DS(on)
Specifications
鈥?/div>
Pin for Pin Replacement for MAX4051 and MAX4051A
鈥?One Half the Resistance Operating at 5.0 Volts
鈥?/div>
Single or Dual Supply Operation
鈥?Single 2.5鈥? Volt Operation, or Dual
鹵3
Volt Operation
鈥?With V
CC
of 3.0 to 3.3 V, Device Can Interface with 1.8 V Logic,
鈥?/div>
No Translators Needed
鈥?Address and Inhibit Logic are Over鈥揤oltage Tolerant and May Be
鈥?/div>
Driven Up +6 V Regardless of V
CC
鈥?/div>
Improved Linearity Over Standard HC4051 Devices
TSSOP鈥?6
DT SUFFIX
CASE 948F
16
9
NLAS
4051
ALYW
1
8
16
9
鈥?/div>
Popular SOIC, and Space Saving TSSOP, and QSOP 16 Pin
Packages
QSOP鈥?6
QS SUFFIX
CASE 492
A
WL, L
Y
WW, W
NLAS
4051
ALYW
1
8
= Assembly Location
= Wafer Lot
= Year
= Work Week
ORDERING INFORMATION
Device
NLAS4051DR2
NLAS4051DTR2
NLAS4051QSR
Package
SO鈥?6
TSSOP鈥?6
QSOP鈥?6
Shipping
2500 Units/Reel
2500 Units/Reel
2500 Units/Reel
漏
Semiconductor Components Industries, LLC, 2002
1
June, 2002 鈥?Rev. 1
Publication Order Number:
NLAS4051/D
