NL7WB66
Ultra鈭扴mall SPST Analog
Switch
The NL7WB66 is a very low R
ON
dual SPST analog switch. R
ON
is
5.0
W
(Typ) at 5.0 V. The device is offered in the very popular low cost
US8 package. It is designed as a general purpose dual switch and can
be used to switch either analog signals such as audio and video or
digital signal such as TTL, CMOS, LVDS, ECL, or complex digital
signals such as QPSK.
Features
http://onsemi.com
MARKING
DIAGRAM
8
US8
US SUFFIX
CASE 493
1
AJ = Device Code
D = Date Code
1
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Excellent Performance RDS
ON
= 5.0
W
at 5.0 V
High Speed Operation: t
PD
= 0.25 ns (Max) at 5.0 V
1.65 to 5.5 V Operating Range
Reduced Threshold Voltages for LVTTL on Control Pin
鈾?/div>
Eliminates the Need for Translators for Many Applications
鈾?/div>
TTL Compatibility when V
CC
is 5.0 V
鈾?/div>
Can Operate with 1.8 V Inputs, if V
CC
is 3.0
鈾?/div>
Also Meets Full CMOS Specifications
Ultra鈭扡ow Charge Injection = 7.5 pC at 5.0 V
Low Stand鈭抌y Power I
CC
= 1.0 nA (Max) at T
A
= 25擄C
Control Pins IN1, IN2, are Overvoltage Tolerant
Pin for Pin Replacement TC7WB66, NC7WB66, 74LVC2G66
Cell Phones
PDAs
Digital Still Cameras
Video
Digital Video
Pin
1
2
3
4
5
6
7
8
8
AJ D
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
NO1
1
8
V
CC
COM1
2
7
OE1
OE2
3
6
COM2
Typical Applications
GND
4
5
NO2
PIN ASSIGNMENT
Function
NO1
COM1
OE2
GND
NO2
COM2
OE1
V
CC
OVT
鈭?/div>
鈭?/div>
Yes
鈭?/div>
鈭?/div>
鈭?/div>
Yes
鈭?/div>
Important Information
鈥?/div>
ESD Protection: MM >200 V, HBM >2000 V
鈥?/div>
Latch鈭扷p Max Rating: 200 mA
FUNCTION TABLE
On/Off
Enable Input
L
H
State of
Analog Switch
Off
On
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 8 of this data sheet.
漏
Semiconductor Components Industries, LLC, 2003
1
August, 2003 鈭?Rev. 1
Publication Order Number:
NL7WB66/D
