DATA SHEET
TFT COLOR LCD MODULE
NL6448AC33-24
26 cm (10.4 inches), 640
脳
480 pixels, 262,144 colors,
Incorporated two-lamp/Edge-light type backlight
Wide viewing angle
DESCRIPTION
NL6448AC33-24 is a TFT (thin film transistor) active matrix color liquid crystal display (LCD) comprising
amorphous silicon TFT attached to each signal electrode, a driving circuit and a backlight. NL6448AC33-24 has a
built-in backlight. Backlight includes long-life-lamps and the lamps are replaceable.
The 26 cm (10.4 inches) diagonal display area contains 640
脳
480 pixels and can display 262,144 colors
simultaneously.
NL6448AC33-24 is suitable for factory automation use, because the viewing angle is ultra wide and the
luminance is high.
FEATURES
鈥?Ultra wide viewing angle
鈥?High luminance (190 cd/m
2
, TYP.)
鈥?Low reflection
鈥?6-bit digital RGB interface
鈥?Data enable (DE) function
鈥?Incorporated edge type backlight with long-life-lamps (Two lamps, with inverter)
鈥?Lamp holder replaceable (Type No.: 104LHS-17L)
鈥?Reversible scan direction
鈥?Approved to UL1950 2nd edition and CSA-C22.2 No.950-93 (File No.: E170632)
APPLICATIONS
鈥?Display terminals for control system
鈥?Monitors for process controller
鈥?Personal computers (PC), Word processor
The information in this document is subject to change without notice.
Document No. MA981113 Version 1
Date Published Nov. 1998 P
Printed in USA
