Designed for 2.3 V to 5.5 V V
CC
Operation
Unbuffered for Crystal Oscillator and Analog Applications
LVCMOS Compatible
24 mA Balanced Output Sink and Source Capability
Near Zero Static Supply Current Substantially Reduces System
Power Requirements
鈥?/div>
Chip Complexity: FET = 72; Equivalent Gate = 18
http://onsemi.com
MARKING
DIAGRAMS
SC鈥?8 / SOT鈥?63/SC鈥?0
DF SUFFIX
CASE 419B
M6
d
Pin 1
d = Date Code
IN A1
1
6
OUT Y1
GND
2
5
V
CC
TSOP鈥?/SOT鈥?3/SC鈥?9
DT SUFFIX
CASE 318G
Pin 1
M6
d
IN A2
3
4
OUT Y2
d = Date Code
Figure 1. Pinout
(Top View)
ORDERING INFORMATION
IN A1
IN A2
1
1
OUT Y1
OUT Y2
See detailed ordering and shipping information in the package
dimensions section on page 4 of this data sheet.
Figure 2. Logic Symbol
PIN ASSIGNMENT
1
IN A1
GND
IN A2
OUT Y2
V
CC
OUT Y1
FUNCTION TABLE
A Input
L
H
Y Output
H
L
2
3
4
5
6
漏
Semiconductor Components Industries, LLC, 2001
1
April, 2001 鈥?Rev. 1
Publication Order Number:
NL27WZU04/D
