NL27WZ14/D Datasheet

  • NL27WZ14/D

  • Dual Schmitt-Trigger Inverter

  • 12頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NL27WZ14
Dual Schmitt-Trigger Inverter
The NL27WZ14 is a high performance dual inverter with
Schmitt鈥揟rigger inputs operating from a 2.3 to 5.5 V supply.
Pin configuration and function are the same as the NL27WZ04, but the
inputs have hysteresis and, with its Schmitt trigger function, the
NL27WZ14 can be used as a line receiver which will receive slow input
signals. The NL27WZ14 is capable of transforming slowly changing input
signals into sharply defined, jitter鈥揻ree output signals. In addition, it has a
greater noise margin than conventional inverters. The NL27WZ14 has
hysteresis between the positive鈥揼oing and the negative鈥揼oing input
thresholds (typically 1.0 V) which is determined internally by transistor
ratios and is essentially insensitive to temperature and supply voltage
variations.
http://onsemi.com
MARKING
DIAGRAMS
鈥?/div>
Designed for 2.3 V to 5.5 V V
CC
Operation
鈥?/div>
Over Voltage Tolerant Inputs and Outputs
鈥?/div>
LVTTL Compatible 鈥?Interface Capability with 5 V TTL Logic
with V
CC
= 3 V
鈥?/div>
LVCMOS Compatible
SC鈥?8 / SOT鈥?63/SC鈥?0
DF SUFFIX
CASE 419B
MA
d
Pin 1
d = Date Code
鈥?/div>
24 mA Balanced Output Sink and Source Capability
鈥?/div>
Near Zero Static Supply Current Substantially Reduces System
Power Requirements
鈥?/div>
Current Drive Capability is 24 mA at the Outputs
TSOP鈥?/SOT鈥?3/SC鈥?9
DT SUFFIX
CASE 318G
Pin 1
MA
d
鈥?/div>
Chip Complexity: FET = 72; Equivalent Gate = 18
d = Date Code
PIN ASSIGNMENT
IN A1
1
6
OUT Y1
1
2
3
GND
2
5
V
CC
4
5
IN A2
3
4
OUT Y2
6
IN A1
GND
IN A2
OUT Y2
V
CC
OUT Y1
Figure 1. Pinout
(Top View)
FUNCTION TABLE
A Input
Y Output
H
L
IN A1
IN A2
OUT Y1
OUT Y2
L
H
Figure 2. Logic Symbol
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 5 of this data sheet.
漏
Semiconductor Components Industries, LLC, 2001
1
April, 2001 鈥?Rev. 1
Publication Order Number:
NL27WZ14/D
