鈥?/div>
Extremely High Speed: t
PD
2.6 ns (typical) at V
CC
= 5.0 V
Designed for 1.65 V to 5.5 V V
CC
Operation
Over Voltage Tolerant Inputs and Outputs
LVTTL Compatible 鈭?Interface Capability With 5.0 V TTL Logic
with V
CC
= 3.0 V
LVCMOS Compatible
24 mA Balanced Output Sink and Source Capability
Near Zero Static Supply Current Substantially Reduces System
Power Requirements
3鈭扴tate OE Input is Active鈭扡ow
Replacement for NC7SZ125
Chip Complexity = 36 FETs
http://onsemi.com
MARKING
DIAGRAM
5
5
1
SC70鈭?/SC鈭?8A/SOT鈭?53
DF SUFFIX
CASE 419A
1
d = Date Code
M0
d
PIN ASSIGNMENT
1
OE
1
5
V
CC
2
3
4
IN A
2
5
OE
IN A
GND
OUT Y
V
CC
FUNCTION TABLE
GND
3
4
OUT Y
OE Input
L
L
H
X = Don鈥檛 Care
A Input
L
H
X
Y Output
L
H
Z
Figure 1. Pinout
(Top View)
OE
IN A
EN
OUT Y
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 6 of this data sheet.
Figure 2. Logic Symbol
漏
Semiconductor Components Industries, LLC, 2004
1
March, 2004 鈭?Rev. 2
Publication Order Number:
NL17SZ125/D
