NL17SZ02
2鈭捍nput NOR Gate
The NL17SZ02 is a single 2-input NOR Gate in two tiny footprint
packages. The device performs much as LCX multi-gate products in
speed and drive.
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Tiny SOT- 353 and SOT-553 Packages
2.4 ns T
PD
at 5 V (typ)
Source/Sink 24 mA at 3.0 V
Over-Voltage Tolerant Inputs
Pin For Pin with NC7SZ02P5X, TC7SZ02FU and TC7SZ02AFE
Chip Complexity: FETs = 20
Designed for 1.65 V to 5.5 V V
CC
Operation
http://onsemi.com
MARKING
DIAGRAMS
5
1
SOT-353/SC70-5/SC-88A
DF SUFFIX
CASE 419A
d = Date Code
5
5
1
5
L3
d
B
1
5
V
CC
1
SOT-553
XV5 SUFFIX
CASE 463B
1
L3 D
A
2
GND
3
4
Y
L3
D
= Device Marking
= One Digit Date Code
PIN ASSIGNMENT
Figure 1. Pinout
(Top View)
Pin
1
2
A
B
w1
Y
3
4
Function
A
B
GND
Y
V
CC
Figure 2. Logic Symbol
5
FUNCTION TABLE
Output
Input
A
L
L
H
H
B
L
H
L
H
Y=A
)
B
Y
H
L
L
L
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 4 of this data sheet.
漏
Semiconductor Components Industries, LLC, 2003
1
February, 2003 - Rev. 2
Publication Order Number:
NL17SZ02/D
