S-Band Radar Front End
NJS 4310D
NJS4310D is designed for the front end of radar system.
It features a small size and a light weight operable at any frequency
between 3.02GHz and 3.08GHz
This front end module consists of GaAs FET low noise amplifier. image
rejection mixer. local VCO with buffer amplifier.
FET monitoring circuit is included to monitor FET drain current.
The stability of the local VCO frequency by the input RF power is
increased effectively by the buffer amplifier which is located between
image rejection mixer and local VCO.
---
ELECTRICAL ---
< at 25
擄C
>
Min
11.8
-
-
3.17
-
6.0
-5
-
-
-
Typical
12.0
-
-
-
-
-
-
50
-
-
Max
12.2
100
3.05
-
3.0
-
-
-
600
400
Unit
V
mA
GHz
GHz
dB
dB
dBm
mV
mW
mW
Operating Voltage 路路路路路路路路路路路路路路路路路路路路
Operating current 路路路路路路路路路路路路路路路路路路路路
Local frequency V
T
= 4V 路路路路路路路路路路路路路路路
V
T
= 24V 路路路路路路路路路路路路路路
Noise figure(Note3) 路路路路路路路路路路路路路路路路路路
Conversion gain(Note3) 路路路路路路路路路路路路路路路
1dB Gain compression point(IF Port) 路路
Monitor voltage 路路路路路路路路路路路路路路路路路路路路路路
RF single pulse burnout(Note1) 路路路路路路路
RF repetitive Pulse burnout(Note2) 路路路
Note1, f=3.05GHz Pd10nsec
NOte2, f=3.05GHZ Pd=1碌s Duty=0.001
Note3, Temperature Range Ta=-30deg. - +90deg.
---
BLOCK DIAGRAM ---
For further information on the use of the front end, please contact
New JRC. New JRC reserves the right to change the specification of goods
without notice.
98-1
