NJG1714KC1

1.9GHz BAND FRONT-END GaAs MMIC

s

GENERAL DESCRIPTION

NJG1714KC1 is a front-end GaAs MMIC including a

LNA, a local amplifier and a mixer, designed mainly for

1.9GHz band cellular phone handsets.

The external adjustment circuit is built into NJG1714KC1.

The ultra small & ultra thin FLP10 package is applied.

s

FEATURES

qLow

Voltage Operation

qLow

Current Consumption

s

PACKAGE OUTLINE

NJG1714KC1

qUltra

Small & Ultra Thin package

[LNA]

qHigh

Small Signal Gain 15.0dB typ. @ f

RF

=1900MHz

qLow

Noise Figure

1.3dB typ. @ f

RF

=1900MHz

qOIP3

+13.0dBm typ. @ f

RF

=1900.0+1900.1MHz

[Mixer]

qHigh

Conversion Gain 9.0dB typ.

@ f

RF

=1900MHz, f

LO

=1660MHz, P

LO

=-15dBm

qLow

Noise Figure

7.0dB typ.

@ f

RF

=1900MHz, f

LO

=1660MHz, P

LO

=-15dBm

qOIP3

+11.0dBm typ. @ f

RF

=1900.0+1900.1MHz, f

LO

=1660MHz, P

LO

=-15dBm

s

PIN CONFIGURATION

+2.7V typ.

LNA 2.8mA typ.

Mixer 5.0mA typ. (with Local Amplifier operation current)

FLP10-C1 (Mount Size: 2.8 x 3.0 x 0.75mm)

FLP10-C1

(Top View)

Orientation Mark

Pin Connection

1.LNAIN

2.LNACAP

3.GND

4.IFOUT

5.VLO

6.LOIN

7.BPC

8.MIXIN

9.GND

10.LNAOUT

NOTE: Please note that any information on this catalog will be subject to change.

-1-
