NID9N05CL
Power MOSFET
9 Amps, 52 Volts
N-Channel, Logic Level, Clamped
MOSFET w/ ESD Protection in a
DPAK Package
Benefits
http://onsemi.com
鈥?/div>
High Energy Capability for Inductive Loads
鈥?/div>
Low Switching Noise Generation
Features
9 AMPERES
52 V CLAMPED
R
DS(on)
= 90 mW (Typ.)
Drain
(Pins 2, 4)
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Diode Clamp Between Gate and Source
ESD Protection - HBM 5000 V
Active Over-Voltage Gate to Drain Clamp
Scalable to Lower or Higher R
DS(on)
Internal Series Gate Resistance
Gate
(Pin 1)
R
G
Overvoltage
Protection
M
PWR
Applications
鈥?/div>
Automotive and Industrial Markets:
Solenoid Drivers, Lamp Drivers, Small Motor Drivers
MAXIMUM RATINGS
(T
J
= 25擄C unless otherwise noted)
Rating
Drain-to-Source Voltage Internally Clamped
Gate-to-Source Voltage - Continuous
Drain Current - Continuous @ T
A
= 25擄C
Drain Current
- Single Pulse (tp = 10
ms)
Total Power Dissipation @ T
A
= 25擄C
Operating and Storage Temperature Range
Single Pulse Drain-to-Source Avalanche En-
ergy - Starting T
J
= 125擄C
(V
DD
= 50 V, I
D(pk)
= 1.5 A, V
GS
= 10 V, R
G
=
25
W)
Thermal Resistance - Junction-to-Case
- Junction-to-Ambient (Note 1)
- Junction-to-Ambient (Note 2)
Maximum Lead Temperature for Soldering
Purposes, 1/8鈥?from Case for 10 Sec.
Symbol
V
DSS
V
GS
I
D
I
DM
P
D
T
J
, T
stg
E
AS
Value
52-59
鹵12
9.0
35
28.8
-55 to
175
160
Unit
Vdc
Vdc
A
W
擄C
mJ
ESD Protection
Source
(Pin 3)
MARKING
DIAGRAM
1
DPAK
CASE 369A
STYLE 2
D9N05CL
Y
WW
= Device Code
= Year
= Work Week
2
3
YWW
X
4
D9N05CL
1
2
3
4
= Gate
= Drain
= Source
= Drain
R
qJC
R
qJA
R
qJA
T
L
5.2
72
100
260
擄C/W
ORDERING INFORMATION
擄C
Device
NID9N05CLT4
NID9N05CL
Package
DPAK
DPAK
Shipping
2500/Tape & Reel
75 Units/Rail
1. When surface mounted to an FR4 board using 1鈥?pad size, (Cu area 1.127 in
2
)
2. When surface mounted to an FR4 board using minimum recommended pad
size, (Cu area 0.412 in
2
)
漏
Semiconductor Components Industries, LLC, 2003
1
March, 2003 - Rev. 3
Publication Order Number:
NID9N05CL/D
