NET2 AC-DC Series Data Sheet
Advance Product Release
Features
鈥?400W output power with currents over 100 Amps
鈥?85% efficiency (typical)
鈥?5-output construction
鈥?Isolated V2 and V3 outputs
鈥?Standby output of 5V @ 2A
鈥?Fits 1U chassis height constraints
鈥?No minimum load requirement
鈥?Active current-share capabilities with redundant
capabilities on the four main outputs
鈥?Patented high-efficiency design
鈥?Meets European power factor requirements
鈥?Excellent load transient response
鈥?Redundancy without use of ORing diode
Description
Designed to meet the stringent requirements of today鈥檚 high-speed circuitry, Power-One鈥檚 NET2 Series is an excellent
compact power solution for low-voltage, high-current applications. The NET2鈥檚 high efficiency is achieved through the
use of synchronous rectification and a newly-patented 鈥淪oft Transition Forward Converter鈥?
The NET2鈥檚 rectification method lowers output losses, reduces system cooling requirements (allowing greater power
in a smaller package), and eliminates minimum-load requirements.
Advanced surface-mount design and packing technology reduce the NET2鈥檚 height to 1.59鈥?(40.3mm) to fit in 1U
applications. NET2鈥檚 high-performance active power factor circuitry meets EN61000-3-2 requirements for compliance
with European Power Line Harmonic Requirements for 2001. A multifunctional output terminal allows connection to #8
ring lugs, 0.25鈥?quick disconnects, cable connectors, and PCB-mounted connectors.
Multiple-Output Model Selection
鈥?/div>
400W WITH 460 LFM FORCED-AIR COOLING
MODEL
OUTPUT
VOLTAGE
ADJUSTMENT
RANGE
OUTPUT
CURRENT
LINE
REGULATION
LOAD & CROSS-
REGULATION
RIPPLE & NOISE
Pk-Pk
(NOTE 2)
INITIAL SETTING
ACCURACY
(NOTE 3)
V1
NET2-4350
(Note1)
V2
V3
V4
V5
V1
NET2-4231
(Note1,4) V2
V3
V4
V5
+3.3V
12V
12V
+5V
+5.2VSB
+3.3V
12V
1.8V
+2.5V
+5.2VSB
+5%, -2%
+5%, -5%
+5%, -5%
+5%, -2%
FIXED
+5%, -2%
+5%, -5%
+5%, -2%
+5%, -2%
FIXED
55A
5A
5A
40A
2A
55A
5A
15A
55A
2A
0.6%
0.5%
0.5%
0.5%
0.5%
0.6%
0.5%
0.6%
0.6%
0.5%
1%
1%
1%
1%
4%
1%
1%
1%
1%
4%
50mV
120mV
120mV
50mV
50mV
50mV
120mV
120mV
50mV
50mV
+40mV, -10mV
鹵 70mV
鹵 70mV
+50mV, -10mV
鹵 110mV
+40mV, -10mV
鹵 70mV
鹵 70mV
+30mV, -10mV
鹵 110mV
NOTES:
1) V1 + V2, or V3 + V4 must not exceed 200W.
2) Maximum peak-to-peak noise for a 20 MHz bandwidth.
3) Initial set points: V1 @ 40A, V2 @ 4A, V3 @ 4A, V4 @ 30A, and V5 @ 1A.
4) Consult factory for availability.
