NE3104-RE10A
Printheads
Under development
For Color Photo Printers
(310DPI ; dots / inch)
NE3104-RE10A
The NE3104-RE10 Series are suitable for photo printers which can make direct print out from digital still cameras and
mobile phones. ROHM鈥檚 energy saving technology based on 鈥渟tep-free鈥?structure enables high speed, and high
resolution printing quality.
Applications
Home printers
Mobile Photo printers
Photo kiosk terminals
鈥淧rint club鈥?(color photo printer) terminals
Features
1) Approximately 8擄 tilt-angle with near-edge structure to work with large platen.
2) NF3104-RE10 enables full color printing by keeping the adjacent resistance variation less than
鹵1.5%.
3) Employing of the driver IC capable of high-speed data transfer at 3.3 circuit supply voltage makes the gradation
printing control easier.
4) High dot reproducibility with step-free structure.
External dimensions
(Unit : mm)
114.8
104.96
Dot #1280
Dot #1
5.685
(1.06)
22.7
Print Dire
ction
(2.3)
No.1
No.24
Note: No heat control function inside the thermal printhead. External heat history control is required for high speed printing.
1/4
