NCV7001
Quad Variable Reluctance
Sensor Interface IC
The NCV7001 is a four鈭抍hannel variable reluctance sensor
interface IC. Microprocessor control functions include two polarity
5.0 V programmable resets, two programmable watchdog inputs, and
an enable function (OLE). Two watchdog inputs allow control from
two independent microprocessors.
Open sensor detection capability is provided. During test mode
(NTEST = Low), a high on the OLE pin should provide a high on the
output. A low under these conditions indicates an open load.
This part has been designed to operate in an automotive
environment.
Features
鈥?/div>
Four Channel Capability
鈥?/div>
Differential Inputs
鈥?/div>
Open Sensor Detect
鈥?/div>
5.0 V Supply Operation with RESET and Watchdog Features
鈥?/div>
On鈭扖hip Input Voltage Clamping
鈥?/div>
NCV Prefix for Automotive and Other Applications Requiring Site
and Change Control
Typical Applications
鈥?/div>
Antilock Braking Systems (ABS)
鈥?/div>
Traction Control Systems (TCS)
鈥?/div>
Vehicle Dynamics Control (VDC)
http://onsemi.com
24
1
SO鈭?4L
DW SUFFIX
CASE 751E
MARKING DIAGRAM
24
NCV7001
AWLYYWW
1
A
WL, L
YY, Y
WW, W
= Assembly Location
= Wafer Lot
= Year
= Work Week
PIN CONNECTIONS
RDLY
NTEST
INN1
INP1
INN2
INP2
INP3
INN3
INP4
INN4
THOLD
GND
1
24
NOUT1
NOUT2
WDO
LVI
NLVI
WD2
V
CC
WD1
OLE
WDLY
NOUT3
NOUT4
ORDERING INFORMATION
Device
NCV7001DW
NCV7001DWR2
Package
SO鈭?4L
SO鈭?4L
Shipping
30 Units/Rail
1000 Tape & Reel
漏
Semiconductor Components Industries, LLC, 2003
1
October, 2003 鈭?Rev. 2
Publication Order Number:
NCV7001/D
