NCV4276/D Datasheet

  • NCV4276/D

  • Low-Drop Voltage Regulator

  • 10頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NCV4276
Advance Information
Low鈭扗rop Voltage
Regulator
This industry standard linear regulator has the capability to drive
loads up to 400 mA at 5.0 V, 3.3 V, 2.5 V and 1.8 V, and is also
available in an adjustable version. Package options include DPAK,
D
2
PAK, and TO-220. This device is pin-for-pin compatible with the
Infineon part number TLE4276.
Features
鈥?/div>
5.0 V, 3.3 V, 2.5 V, 1.8 V, or Adjustable,
鹵4%,
400 mA Output Voltage
鈥?/div>
500 mV (max) Dropout Voltage
鈥?/div>
Inhibit Input
鈥?/div>
Very Low Current Consumption
鈥?/div>
Fault Protection
鈾?/div>
+45 V Peak Transient Voltage
鈾?/div>
-42 V Reverse Voltage
鈾?/div>
Short Circuit
鈾?/div>
Thermal Overload
鈥?/div>
NCV Prefix for Automotive and Other Applications Requiring Site
and Change Control
http://onsemi.com
1
5
DPAK
5-PIN
DT SUFFIX
CASE TBD
D
2
PAK
5-PIN
DP SUFFIX
CASE 936A-02
Pin 1. I
2. INH
3. GND
4. NC/VA
5. Q
I
Error
Amplifier
-
+
Current Limit and
Saturation Sense
Q
1
5
TO-220
FIVE LEAD
TQ SUFFIX
CASE 314D
1
5
TO-220
FIVE LEAD
TQVA SUFFIX
CASE 314N
Bandgap
Reference
Thermal
Shutdown
DEVICE MARKING INFORMATION
See general marking information in the device marking
section on page 5 of this data sheet.
5 V Version Only
INH
GND
Adjustable Version Only
VA
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 6 of this data sheet.
Figure 1. Block Diagram
This document contains information on a new product. Specifications and information
herein are subject to change without notice.
漏
Semiconductor Components Industries, LLC, 2003
1
March, 2003 - Rev. 2
Publication Order Number:
NCV4276/D
