NCV4275

Advance Information

5 V Low鈭扗rop Voltage

Regulator

This industry standard linear regulator has the capability to drive

loads up to 450 mA at 5 V. It is available in DPAK, D

2

PAK, and

TO-220 options. This device is pin-for-pin compatible with

Infineon part number TLE4275.

Features

http://onsemi.com

鈥?/div>

5 V,

鹵2%,

450 mA Output Voltage

Very Low Current Consumption

Active RESET

Reset Low Down to V

Q

= 1 V

500 mV (max) Dropout Voltage

Fault Protection

鈾?/div>

+45 V Peak Transient Voltage

鈾?/div>

-42 V Reverse Voltage

鈾?/div>

Short Circuit

鈾?/div>

Thermal Overload

鈥?/div>

NCV Prefix for Automotive and Other Applications Requiring Site

and Change Control

I

Error

Amplifier

+

-

Current Limit and

Saturation Sense

Q

1

5

DPAK

5-PIN

DT SUFFIX

CASE TBD

Pin 1. I

2. RO

3. GND

4. D

5. Q

D

2

PAK

5-PIN

DP SUFFIX

CASE 936A

Bandgap

Reference

Thermal

Shutdown

D

1

5

TO-220

FIVE LEAD

TQ SUFFIX

CASE 314D

1

5

TO-220

FIVE LEAD

TQVA SUFFIX

CASE 314N

Reset

Generator

ORDERING INFORMATION

Device

GND

NCV4275DT

NCV4275DTRK

NCV4275TQ5

NCV4275TQVA5

This document contains information on a product under development.

ON Semiconductor reserves the right to change or discontinue this prod-

uct without notice.

This document, and the information contained herein, is CONFIDENTIAL AND

PROPRIETARY and the property of Semiconductor Components Industries,

LLC., dba ON Semiconductor. It shall not be used, published, disclosed or

disseminated outside of the Company, in whole or in part, without the written

permission of ON Semiconductor. Reverse engineering of any or all of the

information contained herein is strictly prohibited.

E

NCV4275DP

NCV4275DPR5

*Five pin/lead.

Package

DPAK*

D

2

PAK*

D

2

PAK*

TO-220*

STRAIGHT

TO-220*

VERTICAL

Shipping

xxx Units/Rail

xxxx Tape & Reel

50 Units/Rail

750 Tape & Reel

50 Units/Rail

RO

Figure 1. Block Diagram

DEVICE MARKING INFORMATION

See general marking information in the device marking

section on page 6 of this data sheet.

漏

Semiconductor Components Industries, LLC, 2003

1

March, 2003 - Rev. 3

Publication Order Number:

NCV4275/D
