NCS2300 Series
Advance Information
High Voltage Comparators
The NCS2300 Series are ultra鈥搇ow power comparators. These
devices consume only 11
mA
of supply current. They operate at a wide
voltage range of 1.7 V to 12 V. Additional features include no output
phase inversion when transitioning in/out of tri鈥搒tate mode, internal
hysteresis which allows for clean output switching, and rail鈥搕o鈥搑ail
input performance. The NCS2300 Series are available in the tiny
SOT23鈥? or SOT23鈥? package with two industry standard pinouts.
The NCS2301/3 Series in the SOT23鈥? package features an enable
function which can be externally controlled. This lowers current
consumption to 1.8
mA
and allows for users to implement these
devices in power sensitive applications such as portable electronics.
Features
http://onsemi.com
5
1
SOT23鈥?
(TSOP鈥?, SC59鈥?)
SN SUFFIX
CASE 483
SOT23鈥?
(TSOP鈥?, SC59鈥?)
SN SUFFIX
CASE 318G
6
1
鈥?/div>
Rail鈥搕o鈥揜ail Input/Output Performance
鈥?/div>
Low Supply Current of 11
mA
鈥?/div>
No Phase Inversion/Glitchless transitioning in or out of
Tri鈥揝tate Mode
鈥?/div>
Complementary or Open Drain Output Configuration
鈥?/div>
Available with the Enable Function
鈥?/div>
Tiny SOT23鈥? and SOT23鈥? Package
Typical Applications
PIN CONNECTIONS
Output
V
CC
Non鈥揑nverting
Input
1
2
3
4
Inverting
Input
5
V
EE
Style 1 Pinout (SN1T1)
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Output
V
EE
Non鈥揑nverting
Input
1
2
3
5
V
CC
Inverting
Input
Portable Electronics
Window Comparator
Voltage Detector
Zero鈥揅rossing Detectors
Personal Digital Assistants
4
Style 2 Pinout (SN2T1)
SOT23鈥?
Output
V
CC
Non鈥揑nverting
Input
Output
1
2
3
6
5
5
4
V
EE
Enable
Inverting
Input
Non鈥搃nverting Input
Inverting Input
+
-
Style 1 Pinout (SN1T1)
Output
1
2
3
6
5
5
4
V
CC
Enable
Inverting
Input
This device contains 121 active transistors.
V
EE
Non鈥揑nverting
Input
Style 2 Pinout (SN2T1)
SOT23鈥?
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 11 of this data sheet.
This document contains information on a new product. Specifications and information
herein are subject to change without notice.
DEVICE MARKING INFORMATION
See general marking information in the device marking
section on page 11 of this data sheet.
漏
Semiconductor Components Industries, LLC, 2002
1
January, 2002 鈥?Rev. 0
Publication Order Number:
NCS2300/D
