NCP5162/D Datasheet

  • NCP5162/D

  • General Purpose Synchronous Buck Controller

  • 194.61KB

  • 16頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NCP5162
General Purpose
Synchronous Buck Controller
The NCP5162 is a synchronous dual N鈥揅hannel buck controller
designed to provide unprecedented transient response for today鈥檚
demanding high鈥揹ensity, high鈥搒peed logic. It operates using a
proprietary control method which allows a 100 ns response time to
load transients. The NCP5162 is designed to operate over a 9鈥?6 V
range (V
CC
) using 12 V to power the IC and 5.0 V as the main supply
for conversion.
The NCP5162 is specifically designed for high performance core
logic. It includes the following features: 0.8% output tolerance, V
CC
monitor, and programmable Soft Start capability. The NCP5162 is
available in a 16 pin surface mount package.
Features
鈥?/div>
Dual N鈥揅hannel Design
鈥?/div>
Excess of 1.0 MHz Operation
鈥?/div>
100 ns Transient Response
鈥?/div>
2.0 A Gate Drivers
鈥?/div>
1.02 V Reference Voltage with 0.8% Tolerance
鈥?/div>
5.0 V & 12 V Operation
鈥?/div>
Remote Sense
鈥?/div>
Programmable Soft Start
鈥?/div>
Lossless Short Circuit Protection
鈥?/div>
V
CC
Monitor
鈥?/div>
V
2
鈩?/div>
Control Topology
鈥?/div>
Overvoltage Protection
http://onsemi.com
MARKING
DIAGRAM
16
SO鈥?6
D SUFFIX
CASE 751B
1
A
WL, L
YY, Y
WW, W
= Assembly Location
= Wafer Lot
= Year
= Work Week
NCP5162
AWLYWW
PIN CONNECTIONS
1
Disable
NC
NC
NC
SS
NC
C
OFF
V
FFB
16
V
FB
COMP
LGND
V
CC1
V
GATE(L)
PGND
V
GATE(H)
V
CC2
ORDERING INFORMATION
Device
NCP5162D
NCP5162DR2
Package
SO鈥?6
SO鈥?6
Shipping
48 Units/Rail
2500 Tape & Reel
漏
Semiconductor Components Industries, LLC, 2001
1
August, 2001 鈥?Rev. 3
Publication Order Number:
NCP5162/D
