NCP3418, NCP3418A
Dual Bootstrapped 12 V
MOSFET Driver with
Output Disable
The NCP3418 and NCP3418A are dual MOSFET gate drivers
optimized to drive the gates of both high鈭抯ide and low鈭抯ide power
MOSFETs in a synchronous buck converter. Each of the drivers is
capable of driving a 3000 pF load with a 25 ns propagation delay and a
20 ns transition time.
With a wide operating voltage range, high or low side MOSFET
gate drive voltage can be optimized for the best efficiency. Internal,
adaptive nonoverlap circuitry further reduces switching losses by
preventing simultaneous conduction of both MOSFETs.
The floating top driver design can accommodate VBST voltages as
high as 30 V. Both gate outputs can be driven low by applying a low
logic level to the Output Disable (OD) pin. An Undervoltage Lockout
function ensures that both driver outputs are low when the supply
voltage is low, and a Thermal Shutdown function provides the IC with
overtemperature protection. The NCP3418A is identical to the
NCP3418 except that there is no internal charge pump diode.
The NCP3418 is pin鈭抰o鈭抪in compatible with Analog Devices
ADP3418 with the following advantages:
鈥?/div>
Faster Rise and Fall Times
鈥?/div>
Internal Charge Pump Diode Reduces Cost and Parts Count
鈥?/div>
Thermal Shutdown for System Protection
鈥?/div>
Integrated OVP
鈥?/div>
Internal Pulldown Resistor Suppresses Transient Turn On of Either
MOSFET
Features
http://onsemi.com
MARKING
DIAGRAM
8
1
SO鈭?
D SUFFIX
CASE 751
8
3418
ALYW
1
8
A
L
Y
W
= Assembly Location
= Wafer Lot
= Year
= Work Week
1
3418A
ALYW
PIN CONNECTIONS
BST
IN
OD
VCC
1
8
DRVH
SW
PGND
DRVL
ORDERING INFORMATION
Device
NCP3418D
NCP3418DR2
NCP3418ADR2
NCP3418ADR2G
Package
SO鈭?
SO鈭?
SO鈭?
SO鈭?
Shipping
鈥?/div>
98 Units/Rail
2500 Tape & Reel
2500 Tape & Reel
2500 Tape & Reel
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Anti Cross鈭扖onduction Protection Circuitry
Floating Top Driver Accommodates Boost Voltages of up to 30 V
One Input Signal Controls Both the Upper and Lower Gate Outputs
Output Disable Control Turns Off Both MOSFETs
Complies with VRM 10.x Specifications
Undervoltage Lockout
Thermal Shutdown
Pb鈭扚ree Package is Available
鈥燜or information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specification
Brochure, BRD8011/D.
漏
Semiconductor Components Industries, LLC, 2004
1
January, 2004 鈭?Rev. 8
Publication Order Number:
NCP3418/D
