Quiescent Current of 0.5
碌A
Typical
High Accuracy Under Voltage Threshold of 2.0%
Externally Programmable Time Delay Generator
Wide Operating Voltage Range of 0.8 V to 10 V
Complementary or Open Drain Output
Active Low or Active High Reset
Microprocessor Reset Controller
Low Battery Detection
Power Fail Indicator
Battery Backup Detection
4 N.C.
xxx = 302 or 303
Y
= Year
W = Work Week
(Top View)
Typical Applications
ORDERING INFORMATION
See detailed ordering and shipping information in the ordering
information section on page 21 of this data sheet.
Representative Block Diagrams
NCP302xSNxxT1
Complementary Output Configuration
2
Input
2
NCP303LSNxxT1
Open Drain Output Configuration
Input
1
Reset Output
R
D
1
R
D
V
ref
*
3
Gnd
5
C
D
Reset
Output
V
ref
3
Gnd
5
C
D
*
Inverter for active low devices.
*
Buffer for active high devices.
This device contains 28 active transistors.
