NCP2890
1.0 Watt Audio Power
Amplifier
The NCP2890 is an audio power amplifier designed for portable
communication device applications such as mobile phone
applications. The NCP2890 is capable of delivering 1.0 W of
continuous average power to an 8.0
W
BTL load from a 5.0 V power
supply, and 320 mW to a 4.0
W
BTL load from a 2.6 V power supply.
The NCP2890 provides high quality audio while requiring few
external components and minimal power consumption. It features a
low鈭抪ower consumption shutdown mode, which is achieved by
driving the SHUTDOWN pin with logic low.
The NCP2890 contains circuitry to prevent from 鈥減op and click鈥?/div>
noise that would otherwise occur during turn鈭抩n and turn鈭抩ff
transitions.
For maximum flexibility, the NCP2890 provides an externally
controlled gain (with resistors), as well as an externally controlled
turn鈭抩n and turn鈭抩ff times (with the bypass capacitor).
Due to its excellent PSRR, it can be directly connected to the
battery, saving the use of an LDO.
This device is available in a 9鈭扨in Flip鈭扖hip CSP (standard
Tin鈭扡ead and Lead鈭扚ree versions) and a Micro8 package.
Features
http://onsemi.com
MARKING
DIAGRAMS
9鈭扨in Flip鈭扖hip CSP
FC SUFFIX
CASE 499E
MAx
YYWW
A1
8
8
1
1
x
= Specific Device Code,
G or H
R
= Assembly Location
YY, Y = Year
WW, W = Work Week
Micro8E
DM SUFFIX
CASE 846A
MAB
RYW
1
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
1.0 W to an 8.0
W
BTL Load from a 5.0 V Power Supply
Excellent PSRR: Direct Connection to the Battery
蘆 Pop and Click 祿 Noise Protection Circuit
Ultra Low Current Shutdown Mode
2.2 V鈭?.5 V Operation
External Gain Configuration Capability
External Turn鈭抩n and Turn鈭抩ff Time Configuration Capability
Up to 1.0 nF Capacitive Load Driving Capability
Thermal Overload Protection Circuitry
PIN CONNECTIONS
9鈭扨in Flip鈭扖hip CSP
A1
INM
B1
VM_P
C1
BYPASS
A2
OUTA
B2
VM
C2
A3
INP
B3
V
p
C3
Typical Applications
鈥?/div>
Portable Electronic Devices
鈥?/div>
PDAs
鈥?/div>
Wireless Phones
OUTB SHUTDOWN
(Top View)
Micro8
SHUTDOWN
BYPASS
INP
INM
1
2
3
4
(Top View)
8
7
6
5
OUTB
VM
V
p
OUTA
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 14 of this data sheet.
漏
Semiconductor Components Industries, LLC, 2003
1
October, 2003 鈭?Rev. 6
Publication Order Number:
NCP2890/D
