NCP1573/D Datasheet

  • NCP1573/D

  • Low Voltage Synchronous Buck Controller

  • 16頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NCP1573
Low Voltage Synchronous
Buck Controller
The NCP1573 is a low voltage buck controller. It provides the
control for a DC鈥揇C power solution producing an output voltage as
low as 0.980 V over a wide current range. The NCP1573鈥揵ased
solution is powered from 12 V with the output derived from a 2鈥? V
supply. It contains all required circuitry for a synchronous NFET buck
regulator using the V
2
餂?/div>
control method to achieve the fastest possible
transient response and best overall regulation. NCP1573 operates at a
fixed internal 200 kHz frequency and is packaged in an SO鈥?.
This device provides Power Good with delay and built鈥搃n adaptive
non鈥搊verlap.
Features
鈥?/div>
0.980 V
鹵
1.0% Reference Voltage
鈥?/div>
V
2
Control Topology
鈥?/div>
200 ns Transient Response
鈥?/div>
Power Good
鈥?/div>
Programmable Power Good Delay
鈥?/div>
40 ns Gate Rise and Fall Times (3.3 nF Load)
鈥?/div>
Adaptive FET Non鈥揙verlap Time
鈥?/div>
Fixed 200 kHz Oscillator Frequency
鈥?/div>
On/Off Control Through Use of the COMP Pin
鈥?/div>
Overvoltage Protection through Synchronous MOSFETs
鈥?/div>
Synchronous N鈥揅hannel Buck Design
鈥?/div>
Dual Supply, 12 V Control, 2鈥? V Power Source
http://onsemi.com
8
1
SO鈥?
D SUFFIX
CASE 751
PIN CONNECTIONS AND
MARKING DIAGRAM
V
CC
PWRGD
PGDELAY
COMP
A
L
Y
W
1
1573
ALYW
8
GND
V
FB
GATE(L)
GATE(H)
= Assembly Location
= Wafer Lot
= Year
= Work Week
ORDERING INFORMATION
Device
NCP1573D
NCP1573DR2
Package
SO鈥?
SO鈥?
Shipping
98 Units/Rail
2500 Tape & Reel
錚?/div>
Semiconductor Components Industries, LLC, 2002
1
August, 2002 鈥?Rev. 3
Publication Order Number
NCP1573/D
