NCP1560/D Datasheet

  • NCP1560/D

  • Full Featured Voltage Mode PWM Controller

  • 12頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NCP1560
Product Preview
Full Featured Voltage Mode
PWM Controller
The NCP1560 PWM controller contains all of the features and
flexibility needed to implement voltage鈥搈ode control for modern
high performance power converters. This device cost effectively
reduces system part count with the inclusion of a high鈥搗oltage
start鈥搖p regulator that operates over a wide input range of 33 V to
150 V. The NCP1560 provides two control outputs, OUT1 which
controls the main PWM switch and OUT2 with adjustable over鈥搇ap
delay, which can control a synchronous rectifier. Other distinctive
features include: two mode over鈥揷urrent protection, line under/over
voltage lockout, fast line feed鈥揻orward, soft鈥搒tart and a maximum
duty cycle clamp.
Features
http://onsemi.com
MARKING
DIAGRAM
16
SO鈥?6
D SUFFIX
CASE 751B
1
1
A
WL, L
YY, Y
WW, W
= Assembly Location
= Wafer Lot
= Year
= Work Week
16
TBD
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Internal High Voltage Start鈥搖p Regulator
Dual Control Outputs with Adjustable Over鈥揕ap Delay
Single Resistor Oscillator Frequency Setting
Fast Line Feed鈥揊orward
Line Under/Over Voltage Lockout
Dual Mode Over鈥揅urrent Protection
Programmable Maximum Duty Cycle Control
Maximum Duty Cycle Proportional to Line Voltage
Programmable Soft鈥揝tart
Precision Reference
Telecommunication Power Converters
Industrial Power Converters
High Voltage Power Modules
+42 V Automotive Systems
Control Driven Synchronous Rectifier Power Converters
ORDERING INFORMATION
Device
NCP1560D
NCP1560DR2
Package
SO鈥?6
SO鈥?6
Shipping
48 Units/Rail
2500 Units/Reel
Typical Applications
This document contains information on a product under development. ON Semiconductor
reserves the right to change or discontinue this product without notice.
漏
Semiconductor Components Industries, LLC, 2001
1
February, 2001 鈥?Rev. 0
Publication Order Number
NCP1560/D
