NCP1086
1.5 A Adjustable
and 3.3 V Fixed Output
Linear Regulator
The NCP1086 linear regulator provides 1.5 A at 3.3 V or adjustable
output voltage. The adjustable output voltage device uses two external
resistors to set the output voltage within a 1.25 V to 5.5 V range.
The regulators is intended for use as post regulator and
microprocessor supply. The fast loop response and low dropout
voltage make this regulator ideal for applications where low voltage
operation and good transient response are important.
The circuit is designed to operate with dropout voltages less than
1.4 V at 1.5 A output current. Device protection includes overcurrent
and thermal shutdown.
This device is pin compatible with LT1086 family of linear
regulators and has lower dropout voltage.
The regulators are available in TO鈥?20, surface mount D
2
PAK, and
SOT鈥?23 packages.
Features
鈥?/div>
Output Current to 1.5 A
鈥?/div>
Output Accuracy to
鹵
1% Over Temperature
鈥?/div>
Dropout Voltage (typical) 1.05 V @ 1.5 A
鈥?/div>
Fast Transient Response
鈥?/div>
Fault Protection Circuitry
鈥?/div>
Current Limit
鈥?/div>
Thermal Shutdown
APPLICATION DIAGRAMS
5.0 V
V
IN
NCP1086
Adj
10
碌F
5.0 V
124
鈩?/div>
1.0%
0.1
碌F
5.0 V
Tantalum
22
碌F
5.0 V
200
鈩?/div>
1.0%
V
OUT
3.3 V
@ 1.5 A
http://onsemi.com
TO鈥?20
THREE LEAD
T SUFFIX
CASE 221A
1
2
3
D
2
PAK
3鈥揚(yáng)IN
D2T SUFFIX
CASE 418E
3
SOT鈥?23
ST SUFFIX
CASE 318E
Adjustable
Output
Tab = V
OUT
Pin 1. Adj
2. V
OUT
3. V
IN
3.3 V Fixed
Output
Tab = V
OUT
Pin 1. GND
2. V
OUT
3. V
IN
12
1
23
ORDERING INFORMATION
鈥?/div>
Device
NCP1086T鈥揂DJ
NCP1086D2T鈥揂DJ
NCP1086D2T鈥揂DJR4
NCP1086ST鈥揂DJT3
NCP1086T鈥?3
NCP1086D2T鈥?3
NCP1086D2T鈥?3R4
Package
TO鈥?20*
D
2
PAK*
D
2
PAK
Shipping
50 Units/Rail
50 Units/Rail
750 Tape & Reel
SOT鈥?23* 2500 Tape & Reel
TO鈥?20
D
2
PAK
D
2
PAK
50 Units/Rail
50 Units/Rail
750 Tape & Reel
Adjustable Output
3.3 V
@ 1.5 A
NCP1086ST鈥?3T3
SOT鈥?23 2500 Tape & Reel
V
IN
NCP1086
GND
10
碌F
5.0 V
V
OUT
* TO鈥?20 are all 3鈥損in, straight leaded. D
2
PAK and
SOT鈥?23 are all 3鈥損in.
鈥燗dditional ordering information can be found on
page 9 of this data sheet.
22
碌F
5.0 V
DEVICE MARKING INFORMATION
See general marking information in the device marking
section on page 9 of this data sheet.
3.3 V Fixed Output
漏
Semiconductor Components Industries, LLC, 2000
1
November, 2000 鈥?Rev. 0
Publication Order Number:
NCP1086/D
